5000W DIP Transient Voltage Suppressors Diodes 5KP Series

Description of 5000W DIP Transient Voltage Suppressors Diodes 5KP Series
The 5000W DIP Transient Voltage Suppressors Diodes 5KP Series is designed specifically to protect sensitive electronic equipment from voltage transients induced by lightning and other transient voltage events.

Features of 5000W DIP Transient Voltage Suppressors Diodes 5KP Series
Fast response time
Matte tin lead–free Plated
Low incremental surge resistance
Halogen free and RoHS compliant
Typical IR less than 2μA above 10V
Compatible with industrial standard package P600
For surface mounted applications to optimize board space
5000W peak pulse power capability with at 10/1000μs waveform, repetition rate (duty cycle): 0.01%
High temperature soldering guaranteed:260°C/10 seconds

Category: Tags: , , , , ,

Description

The 5000W DIP Transient Voltage Suppressors Diodes 5KP Series transient suppression diodes are used in computer systems, communication equipment, and suitable for the protection of DC Port, RS485/232/422, I/O Port and other ports. It has fast response time and transient High power, low leakage current, breakdown voltage deviation, easy control of clamping voltage, no damage limit, high reliability, strong current capacity, small size and other advantages, package: P600, voltage range: 5.0～440V.

5000W DIP Transient Voltage Suppressors Diodes 5KP Series
